Engine	Model	Bucket Capacity
73.0 kW/ 2,000 min^-1 (ISO 14396 Without Fan)	ISUZU 4JJ1	0.50 - 0.57 m³

Engine	73.0 kW/ 2,000 min^-1 (ISO 14396 Without Fan)
Model	ISUZU 4JJ1
Bucket Capacity	0.50 - 0.57 m³

This series can be used for industry:: Construction & Civil Works; Agribusiness; Forestry

Download Brochure: SK130-10E (SK140LC-10E).PDF

Main Specifications

Model Name	SK130	SK140LC
Machine Type	SK130-10E	SK140LC-10E

Engine

Model		ISUZU 4JJ1
Type		Four cycle, water cooled, overhed camshaft, vertical in-line, direct injection type, with turbocharger
Rated power output	kW/min^-1	65.4 / 2,000 (ISO 9249 With Fan) 73.0 / 2,000 (ISO 14396 Without Fan)

Hydraulic System

Hydraulic Oil Tank (system)	L	94.5 (197)
Pump Type		Two variable displacement pumps + one gear pump
Pump Max.Discharge flow	L/min	2 x 130.4, 1 x 20

Swing System

Swing speed	min^-1{rpm}	10.9

Travel System

Travel Speed (high / low)	km/h	5.7 / 3.3
Drawbar pulling force	kN{kgf}	142{14,500}(SAE)
Gradeability	% ( º )	70 (35)
Travel motors		2 x axial-piston, two-step motors

Refilling Capacities & Lubrications

Fuel Tank	L	271

Attachments

Bucket capacity ISO heaped	m³	0.50 0.57 0.57HD
Bucket capacity ISO Struck	m³	0.38 0.43 0.43

Operating Weight

Operating Weight SK130	kg	12,600 - 13,100
Operating Weight SK140LC	kg	13,300 - 13,800
